Pro Gen4 2MP & 8MP IR PTZ Outdoor
Please choose the product part number
IPS08-P25-OI04
Illustra Pro PTZ 8MP Gen4, Outdoor, 22x Optical Zoom, 12 Digital Zoom, True D/N with IR, True WDR, IK10, IP66 PoE 802.3bt Type4/22-30VAC
0
IPS02-P24-OI04
Illustra Pro PTZ 2MP Gen4, Outdoor, 42x Optical Zoom, 12 Digital Zoom, True D/N with IR, True WDR, IK10, IP66 PoE 802.3bt Type4/22-30VAC
0
The exceptional speed of the Illustra Pro PTZ coupled with ultra-low latency performance gives security personnel the ability to accurately track subjects in mission critical applications.
The camera employs zoom-adjusted program technology to automatically control the pan and tilt speed in proportion to the amount of zoom used, delivering precise pan and tilt control. Using programmed presets and tours, the Illustra Pro PTZ moves into position at up to 700° per second.
Camera Features
- AI Object classification combined with event rules to pinpoint forensic searches or trigger events
- Large zoom capacity to identify important features at a greater distance
- Rain dispersion for a clear image
- 5 year warranty
- Auto-tracking based upon face or person detection
- Image stabilisation for clarity of image at large zoom setting
- True Day/Night and an IR distance up to 200M
- Encrypted, end to end, video streaming for protection of video
- Zubehör
- Ressourcen
- Technische Daten
- Bestellnummern
- What's in the box
Guides
A&E Specifications
Datenblätter
Firmware
Benutzerhandbücher
Quick Start Guide
Behördliche Informationen
Versionshinweise
Technische Zeichnungen
| Kamerafunktionen | Pro Gen4 2MP & 8MP IR PTZ Outdoor |
| AI Object Classification | Classes: Person, Bicycle, Bus, Car, Motorbike, Train, Truck, Trolley, Backpack, Handbag, Suitcase, Any Class |
| Audio | Bi-directional; 1 input, 1 output (line In audio) |
| Alarm Input/Output | 2/2 |
| B/W | Minimum Illumination 2MP 0.0035 lux 8MP (4K) 0.015 lux |
| Color | Minimum Illumination 2MP 0.015 lux 8MP (4K) 0.06 lux |
| Day/Night | TDN CF removal |
| Defog | Yes |
| Digital Noise Reduction | 2D and 3D |
| Dimensions | Ø8.03 x 13.74 in (Ø204 x 349 mm) |
| Ethernet | IEEE 802.3, 10/100/1000Base-T Ethernet, RJ45, auto sensing |
| Field of View | 2MP Wide Angle: 43°/24°, Telephoto: 1.6°/0.9° 8MP (4K) Wide Angle: 61.9°/36.2°, Telephoto: 3.4°/1.7° |
| Focal Length | 2MP 4.5-135 mm - 8MP (4K) 6.4-139 mm |
| Focus | Motorized, Continuous Auto Focus, Manual Focus |
| Focus Control | Motorized |
| H.264 | yes |
| H.265 | yes |
| Housing Color | RAL 9003 - Signal White |
| Imager | 2MP CMOS 1/2.8” - 8MP (4K) CMOS 1/1.18” |
| Image Stabilization | Electric Image Stabilization in Future Firmware releases |
| Intelligent Guard Tour | Face, Person |
| IntelliZip | Yes |
| IR Distance | 2MP Up to 656’ (200m) - 8MP (4K) Up to 492’ (150m) |
| IR Illuminator | yes |
| Lens Type | Varifocal Lens, DC-Iris, IR Corrected |
| Manual Speed | < 0.25° to 100°/s scaled in proportion to zoom position |
| Max Aperture | 2MP F/1.8(W) ~ F/6.5(T) - 8MP F/1.5(W) ~ F/3.4(T) |
| Max Frame Rate | 2MP@60fps - 8MP@30fps/2MP@60fps |
| MJPEG | yes |
| Motion Detection | Yes |
| Onboard Storage | Micro SD/SDHC/SDXC card slot, up to 512GB |
| ONVIF Compliant | Profile S, G, M |
| Operating Temperature | -58 F to +149 F (-50 C to +65 C) |
| Outdoor Rating | IP66 |
| Pan Travel | 360° Continuous |
| Power Input | 802.3bt Type 4 (90W) |
| Power Supply | 22 to 30 VAC & VDC, Class 2 LP 72W |
| Presets | 300 |
| Resolution Options | 2MP - 1920 x 1080, 1664 x 936, 1280 x 720, 1024 x 576, 960 x 544, 816 x 464, 640 x 360, 480 x 272, 640 x 368 8MP - 3840 x 2160, 3264 x 1840, 2688 x 1520, 1920 x 1080, 1664 x 936, 1280 x 720, 1024 x 576, 960 x 544, 816 x 464, 640 x 360, 480 x 272, 640 x 368 |
| Shutter Speed | ≥ 1/10,000 to 1/4 s |
| Supported Protocols | TCP/IP, IPv4, IPv6, TCP, UDP, HTTP, FTP, DHCP, WS-Discovery, DNS, DDNS, RTP, RTCP, RTSP, TLS, Unicast (10 users), Multicast (unlimited users), NTP, ICMP, IGMP, SMTP, WS-Security, IEEE 802.1x, PEAP, EAP-TLS, EAPoL, SSH, HTTPS, SOAP, WSAddressing, CIFS, SNMP, UPNP™, RTSP, LLDP |
| Tilt Travel | +15° to -90° |
| TrickleStor | Yes |
| Vandal-Resistant | IK10 |
| Video Intelligence | Linger, Exit, Direction, Abandoned/Removed objects, Queue, Dwell, Enter, Object detection, Crowd, Perimeter |
| Video Streams | Quad Streaming |
| Weight | 16LBS / 7KG |
| Wide Dynamic Range | True multi shutter WDR 126dB Smart WDR /TrueWDR. TrueWDR3x |
| Zoom | 2MP 42x Optical Zoom, 12x Digital - 8MP (4K) 22x Optical Zoom, 12x Digital |
Kamera-Bestellnummern
| Modellnummer | |
| IPS08-P25-OI04 | Illustra Pro PTZ 8MP Gen4, Outdoor, 22x Optical Zoom, 12 Digital Zoom, True D/N with IR, True WDR, IK10, IP66 PoE 802.3bt Type4/22-30VAC |
| IPS02-P24-OI04 | Illustra Pro PTZ 2MP Gen4, Outdoor, 42x Optical Zoom, 12 Digital Zoom, True D/N with IR, True WDR, IK10, IP66 PoE 802.3bt Type4/22-30VAC |
What's in the box
• 1 x Illustra IR PTZ Camera
• 1 x Printed Quick Start Guide
• 1 x Printed Regulatory Document
• 1 x NTSC/PAL output female BNC cable
• 1 x 2-pin European style terminal block
• 1 x Torx 20 security L-Key & 1 x Torx 10 security L-Key
• 1 x 12-pin terminal connector for I/O function
• 1 x Safety cable (Pre-attached to the camera)
• 1 x Mount adaptor
• 3 x ¼ 20 UNC security screws
• 1 x Rubber grommet
• 1 x RJ45 Insert tool
